k8s kubelet failed to reserve sandbox name

Sometimes containerd files gets corrupted. Why?..

Workaround.

systemctl stop kubelet
systemctl stop containerd

Remove corrupted containerd

mv /var/lib/containerd/ /var/lib/containerd_
mv /run/containerd/ /run/containerd_

Set a specific IP of any k8s api master to work without the missing nginx-proxy

grep localhost /etc/kubernetes/kubelet.conf
server: https://localhost:6443

Return the node to work

systemctl restart kubelet
systemctl restart containerd

Monitoring the start of pods

watch crictl ps

Revert kubelet.conf to localhost

Ceph pgs not deep-scrubbed in time

1. Change scrub_interval

ceph config set osd osd_deep_scrub_interval 1814400
ceph tell osd.* config set osd_deep_scrub_interval 1814400

2. Temporarily increase the number of active scrub tasks

ceph tell 'osd.*' injectargs --osd_max_scrubs=2

3. Check LA and increase osd_scrub_load_threshold

ceph tell 'osd.*' injectargs --osd_scrub_load_threshold=5

4. Force deep scrub tasks

ceph health detail | grep "not deep-scrubbed since" | awk '{ print $2 }' | xargs -n1 ceph pg deep-scrub

nfs-ganesha

Some non-obvious things in the config

cat /etc/ganesha/ganesha.conf

EXPORT
{
Export_ID=1;
Path = "/nfs-stage";
Pseudo = "/nfs-stage";
Access_Type = RW;
Protocols = 4;
Transports = TCP;
Anonymous_Uid = 1000;
Anonymous_Gid = 1000;
FSAL {
Name = RGW;
User_Id = "nfs-stage";
Access_Key_Id ="ACCESS_KEY";
Secret_Access_Key = "SECRET_KEY";
}
CLIENT
{
Clients = 10.10.0.0/24;
Squash = None;
Access_Type = RW;
}
}
RGW {
        ceph_conf = "/etc/ceph/ceph.conf";
        name = "client.admin";
        cluster = "ceph";
        init_args = "--keyring=/etc/ceph/ceph.client.admin.keyring";
}
#LOG {
#        Facility {
#                name = FILE;
#                destination = "/var/log/ganesha.log";
#                enable = active;
#        }
#}

Proxmox. Аналитика выделенных ресурсов

CSV файл со списком всех виртуальных маших и выделенных под них ресурсов

pvesh get /cluster/resources --type vm --output-format json > /tmp/vm_exp_list.json

cat vm_exp_list.json | jq -r 'sort_by(.vmid)|.[]|select(.status == "running")| [.vmid, .node, .name, .maxcpu, .maxmem, .maxdisk]|@csv'

Сбор sFlow в Clickhouse для аналитики

Общая схема:

host-sflow -> sFlow -> goflow2 collector -> kafka protobuf -> clickhouse

1. Серверная часть сборки sflow

https://github.com/netsampler/goflow2
NetFlow/IPFIX/sFlow collector in Go

Kafka

Подготовить топик nflow

goflow2

Запущен в Docker

docker run --net=host -ti netsampler/goflow2:latest -transport=kafka -transport.kafka.brokers=localhost:9092 -transport.kafka.topic=nflow -format=pb -format.protobuf.fixedlen=true



Clickhouse

Скачать настройки протокола protobuf

https://github.com/netsampler/goflow2/blob/main/compose/kcg/clickhouse/protocols.csv

/var/lib/clickhouse/user_files/protocols.csv

Таблицы и подключение к kafka

CREATE TABLE IF NOT EXISTS nflow.flows_kafka

(

time_received UInt64,

time_flow_start UInt64,

sequence_num UInt32,

sampling_rate UInt64,

sampler_address FixedString(16),

src_addr FixedString(16),

dst_addr FixedString(16),

src_as UInt32,

dst_as UInt32,

etype UInt32,

proto UInt32,

src_port UInt32,

dst_port UInt32,

bytes UInt64,

packets UInt64

) ENGINE = Kafka()

SETTINGS

kafka_broker_list = '127.0.0.1:9092',

kafka_topic_list = 'nflow',

kafka_group_name = 'clickhouse',

kafka_format = 'Protobuf',

kafka_schema = 'flow.proto:FlowMessage',

kafka_skip_broken_messages = 1;



CREATE TABLE IF NOT EXISTS nflow.flows_raw

(

date Date,

datetime DateTime,

sequence_num UInt32,

sampling_rate UInt64,

sampler_address String,

src_addr String,

dst_addr String,

src_as UInt32,

dst_as UInt32,

etype UInt32,

proto UInt32,

src_port UInt32,

dst_port UInt32,

bytes UInt64,

packets UInt64

) ENGINE = MergeTree()

PARTITION BY date

ORDER BY datetime

TTL date + toIntervalDay(30)

SETTINGS index_granularity = 8192;



CREATE MATERIALIZED VIEW IF NOT EXISTS nflow.flows_raw_mv TO nflow.flows_raw

AS SELECT

toDate(time_received) AS date,

time_flow_start AS datetime,

sequence_num,

sampling_rate,

IPv4NumToString(reinterpretAsUInt32(substring(reverse(sampler_address), 13, 4))) AS sampler_address,

IPv4NumToString(reinterpretAsUInt32(substring(reverse(src_addr), 13, 4))) AS src_addr,

IPv4NumToString(reinterpretAsUInt32(substring(reverse(dst_addr), 13, 4))) AS dst_addr,

src_as,

dst_as,

etype,

proto,

src_port,

dst_port,

bytes,

packets

FROM nflow.flows_kafka;

2. Установка сборщика флоу на хост

Используем host-sflow

cat /etc/hsflowd.conf
sflow {
  collector { ip=goflow2.host.example.com udpport=6343 }

  # ====== Local configuration ======
  pcap { dev = eth0 }
  pcap { dev = eth1 }
  # ...
}

systemctl enable hsflowd
systemctl start hsflowd

3. Примеры запросов

Активные сборщики флоу

select sampler_address,count() from nflow.flows_raw where datetime>now()-24*3600 group by sampler_address limit 100;

Найти источник запросов на список внешних ресурсов

select src_addr,count() from nflow.flows_raw where datetime>now()-24*3600 and dst_addr in ('1.1.1.1','8.8.8.8') group by src_addr order by count() desc limit 100;

Centos 7 SSH error "shell request failed on channel 0"

Столкнулся с невозможностью подключиться по ssh к нодам k8s под определённым юзером:

ssh user@10.0.0.10
shell request failed on channel 0

Выяснилось, что UID пользователя user был использован в docker image одного из сервисов.

Быстрое решение увеличить лимиты числа процессов для рядовых пользователей в Centos 7, например, на 8192:

/etc/security/limits.d/20-nproc.conf

# Default limit for number of user's processes to prevent
# accidental fork bombs.
# See rhbz #432903 for reasoning.
*          soft    nproc     4096
root       soft    nproc     unlimited

Proxmox ZFS howto find Linked Clone disks

id 200 - proxmox template

id 201 - VM with Linked Clone disk

zfs list -o name,origin
...
rpool/data/vm-201-disk-0 rpool/data/base-200-disk-0@__base__
